Second Hand Robotic Welding Arms FD-B4LS 7 Axis Welding Robot
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | OTC |
| Certification: | CE |
| Model Number: | FD-B4LS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiable |
| Delivery Time: | 6-8working days |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | 999 sets/month |
|
Detail Information |
|||
| Name: | Second Hand Robotic Welding Arms FD-B4LS 7-axis Welding Robot | Brand: | OOTC |
|---|---|---|---|
| Model: | FD-B4LS | Production Year: | 2000-2015 |
| Warranty: | 3 Month | Drive Method: | Electric |
| Payload: | 12kg | Reapetability: | 0.05 Mm |
| Axis: | 6 | ||
| High Light: | Second Hand Robotic Welding Arms,7 Axis Robotic Welding Arms,FD-B4LS Used Fanuc Robot |
||
Product Description
robotic welding arms FD-B4LS 7-axis welding robot extends the reach of B4S welding collaborative robot arms for OTC
| Specification | Value |
|---|---|
| Number of Axes | 7 |
| Maximum Payload Capacity | 4 kg |
| Positional Repeatability | +/- 0.08 mm (Note 1) |
| Horizontal Reach | 2008mm |
| Vertical Reach | 3508mm |
| Drive Capacity | 5650W |
| Working Range, Arm, J1 (Rotation) | +/- 170° |
| Working Range, Arm, J2 (Lower Arm) | -145°~ +70° |
| Working Range, Arm, J3 (Upper Arm) | -170°~ +154° |
| Working Range, Wrist, J4 (Swing) | +/- 155° |
| Working Range, Wrist, J5 (Bending) | -45°~ +225°(Note 2) |
| Working Range, Wrist, J6 (Twist) | +/- 205° (Note 2) |
| Maximum Velocity, Arm, J1 (Rotation) | 3.40 rad/s {195°/s} |
| Maximum Velocity, Arm, J2 (Lower Arm) | 3.49 rad/s {200°/s} |
| Maximum Velocity, Arm, J3 (Upper Arm) | 3.49 rad/s {200°/s} |
| Maximum Velocity, Wrist, J4 (Swing) | 7.33 rad/s {420°/s} |
| Maximum Velocity, Wrist, J5 (Bending) | 7.33 rad/s {420°/s} |
| Maximum Velocity, Wrist, J6 (Twist) | 10.5 rad/s {600°/s} |
| Wrist Load, Allowable Moment, J4 (Swing) | 10.1 N*m |
| Wrist Load, Allowable Moment, J5 (Bending) | 10.1 N*m |
| Wrist Load, Allowable Moment, J6 (Twist) | 2.94 N*m |
| Wrist Load, Allowable Moment of Inertia, J4 (Swing) | 0.38 kg*m^2 |
| Wrist Load, Allowable Moment of Inertia, J5 (Bending) | 0.38 kg *m^2 |
| Wrist Load, Allowable Moment of Inertia, J6 (Twist) | 0.03 kg *m^2 |
| Arm operation cross-sectional area | 5.28 m^2 x 340° |
| Environmental Conditions | 0 ~ 45°C, 20 ~ 80 %RH (No condensation) |
| Mass | 321 kg |
| Upper arm payload capacity | 10 kg (Note 3) |
| Installation type | Floor type |
| Paint color | White (Munsell 10GY9/1) |
Our FD-B4LS 7-axis welding robot extends the reach of our B4S robot model, while incorporating the same through-arm design for tight welding requirements or the need for floor space savings. This long reach (L) robot is perfectly suited for larger, distant or multiple welding zones.
Click here to download more information.
ARC-WELDING ROBOT MANIPULATOR
• Rotation of the 7th-axis enables interference avoidance without changing the position and/or attitude of the end-of-arm tool
• Maintains the optimal angle and attitude of the end-of-arm tool at all times, resulting in enhanced weld quality and ease of programming
• Offers a wide working range with an independently articulated arm
• Seamless digital connection with all OTC DAIHEN brand welding power supplies
• Improved vibration restraining control provides smooth robot movement
• Built-in mechanical shock sensor
• Single source technology – all components are manufactured by OTC Daihen.
• Highly versatile design supports most welding applications
FD11 ROBOT CONTROLLER
• Windows XP based open architecture
• Large memory capacity and 40 Input / 40 Output control signals
• Advanced PLC functions allow for ladder diagram editing directly through the teach pendant
• Network capabilities – connects to Ethernet, DeviceNet, and PROFIBUS connections (may require additional hardware)
TEACH PENDANT
• Icon displays assist in quick & easy teaching
• 640×480 VGA color screen with LED backlight 65536 color display
• 3 position enable switch provides increased safety
• Multi-screen function allows user to view up to 4 screens simultaneously
• On-screen help function with complete instruction manuals
• Standard touch screen display with jog dial operation
