6 Axis Robot Arm Used Industrial Robot 2032MM Reach For Welding
Product Details:
| Place of Origin: | Japan |
| Brand Name: | FANUC |
| Certification: | CE |
| Model Number: | M-10iD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $29,600.00/sets 1-9 sets |
| Packaging Details: | 6 Axis Robot Arm Of Industrial Robot M-10iD/8L With 2032MM Reach As Material Handling Equipment Parts For Welding packing with fumigation wooden frame, WG:1705KG<br>Controller and other parts packing with brown box, WG:75KG<br>Total WG:1780KG(>VG) |
| Supply Ability: | 5 Piece/Pieces per Month |
|
Detail Information |
|||
| Type: | M-10iD/8L | Payload: | 8KG |
|---|---|---|---|
| Reach: | 2032MM | Repeatability: | 0.03MM |
| Weight: | 180KG | Controller: | R-30iB Plus |
| Installation Note: | Floor, Upside-down, Angle Mount | Robot Footprint: | 343*343MM |
| Protection: | IP54/IP67 | Axis: | 6 |
| Condition: | New | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | Hot Product 2019 |
| Warranty Of Core Components: | 1 Year | Core Components: | PLC, Motor |
| Warranty: | 1 Year | After-sales Service Provided: | Video Technical Support, Online Support |
| After Warranty Service: | Video Technical Support, Online Support | Local Service Location: | Canada, United Kingdom, United States, France, Germany, Russia, Spain, Australia |
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert | Showroom Location: | Canada, United Kingdom, United States, Italy, France, Germany, Brazil, Mexico, Russia, Japan, Australia |
| Port: | Shanghai | ||
| High Light: | Second Hand 6 Axis Robot Arm,used Industrial Robot 2032MM Reach,6 Axis Robot Arm 2032MM Reach |
||
Product Description
6 Axis Robot Arm Of used Industrial Robot M-10iD/8L With 2032MM Reach As Material Handling Equipment Parts For Welding
| Axes | 6 |
| Payload | 12 kg |
| Reach | 1441 mm |
| Repeatability | 0.02 mm |
| Robot Mass | 145 kg |
The Fanuc M-10iD/12 robot is a 6-axis robot arm, it offers a 12 kg payload and 1441 mm reach. The repeatability of the Fanuc M-10iD/12 robot is 0.02 mm.
FANUC M-10 Series: The fast, compact solution to all your small handling jobs
The fastest handling robot in its class, the M-10 Series delivers improved throughput and optimized cycle times across a wide range of pick, place and machine tending operations. Weighing just 130 kg, the M-10 boasts up to 12 kg in payload, very high axis speeds and acceleration resulting in high wrist movements. Slim cable-integrated arm and hollow wrist assembly support make for easy operation even in confined work areas.
• Slim wrist design for easy access
Featuring a slim wrist interference radius, the FANUC M-10 is designed for easy integration into small work cells. An additional mounting facility on the J3 arm enables close mounting of end effector control equipment.
• The right wrist for the job
Capable of lifting up to 12 kg, the M-10 series' heavy-duty wrists make it ideal for loading and unloading operations. Hollow or in-line wrist for more strength and stability, improved cable protection and easy maintenance. IP67 waterproof wrist and J4 arm suitable for water jet and die cast applications.
• No external cables to catch or wear
Internal cable routing through the J3 arm and J6 wrist extends cable life and prevents the risk of cable interference. Integrated air and electrical services consisting of 8 inputs and 8 outputs as standard.
Applications:
- Assembly
- Pick/Pack/Palletizing
- Part Transfer
- Material Removal
- Dispensing
More products:
KUKA robot
1: KR 6 R1820 6KG 6axis welding robot
2: KR 6 R700 sixx 6 axis payload 6kg multifunctional industrial robot
3: KR 10 R1420 6 aixs 10kg welding robot
4: KR 210 R2700 EXTRA 210KG payload multifunctional industrial robot
ABB robot
1: IRB 1200/7/0.7 6 axis 7kg payload multifunctional industrial robot
2: IRB 1520ID 6 axis 5kg payload for welding
3: IRB 6700/150/3.2 150 kg payload for handing,cutting and palletizing
Collaborative robot
1: Collaborative robot of Chinese industrial robot arm 6 axis 6kg paylad
2: Collaborative robot of chinese industrial robot arm 7 axis 5kg payload
|
item
|
value
|
|
Place of Origin
|
Japan
|
|
Brand Name
|
FANUC
|
|
Condition
|
New
|
|
Video outgoing-inspection
|
Provided
|
|
Machinery Test Report
|
Provided
|
|
Marketing Type
|
Hot Product 2019
|
|
Warranty of core components
|
1 Year
|
|
Core Components
|
PLC, Motor
|
|
Warranty
|
1 Year
|
|
|
Video technical support, Online support
|
|
After Warranty Service
|
Video technical support, Online support
|
|
Local Service Location
|
Canada, United Kingdom, United States, France, Germany, Russia, Spain, Australia
|
|
Applicable Industries
|
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company
|
|
Showroom Location
|
Canada, United Kingdom, United States, Italy, France, Germany, Brazil, Mexico, Russia, Japan, Australia
|
|
Type
|
M-10iD/8L
|
|
Payload
|
8KG
|
|
Reach
|
2032MM
|
|
Repeatability
|
0.03MM
|
|
Weight
|
180KG
|
|
Controller
|
R-30iB Plus
|
|
Installation note
|
Floor, Upside-down, Angle mount
|
|
Robot footprint
|
343*343MM
|
|
Protection
|
IP54/IP67
|
|
Axis
|
6
|
We are based in Shanghai, China, start from 2015,sell to South America(40.00%),Southeast Asia(30.00%),Eastern Europe(20.00%),Western Europe(5.00%),Domestic Market(5.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Robot/ Robot Positioner/ Robot Track/ Robot Gripper/ Robot Control System
4. why should you buy from us not from other suppliers?
1: We are with ABB,KUKA,FANUC,YASKAWA agentand many other brands agent for years. 2: Majority of our engineer from KUKA, ABB. The engineering manager worked in ABB company for 19 years. 3: We can offer majority of industrial controlled component.
5. what services can we provide?
Accepted Delivery Terms: FOB,EXW；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,Western Union;
Language Spoken:English,Chinese
|
Production Name
|
Industry Robot
|
|
Power supply
|
20 ~ 25V
|
|
Protection rating
|
IP54
|
|
Weight
|
1.25kg
|
