10kg Rated Payload Used Industrial Robot KR 10 R1420 Robotic Welding
Product Details:
| Place of Origin: | Shanghai, China |
| Brand Name: | KUKA |
| Certification: | UL / IEC62619 / IEC62477 / EC62040 / CE / UN38.3 / ETL |
| Model Number: | KR 10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiable |
| Packaging Details: | ONE Industrial robot KR 10 R1420 with 10kg rated payload robotic welding with 6 axis robot arm mig mag welding machine packing with fumigation wooden frame<br>WG:160KG |
| Supply Ability: | 999 Piece/Pieces per Month |
|
Detail Information |
|||
| Maximum Reach: | 1420 Mm | Maximum Payload: | - |
|---|---|---|---|
| Rated Payload: | 10 Kg | Teach Pendant: | KUKA SmartPAD |
| Pose Repeatability (ISO 9283): | ± 0.04 Mm | Number Of Axes: | 6 |
| Footprint: | 333.5 Mm X 307 Mm | Weight: | Approx. 160 Kg |
| Ambient Temperature During Operation: | 5 °C To 45 °C (278 K To 318 K) | Protection Rating (IEC 60529): | IP54 |
| Condition: | New | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | New Product 2020 |
| Warranty Of Core Components: | 1 Year | Core Components: | PLC |
| Warranty: | 1 Year | After-sales Service Provided: | Video Technical Support, Online Support |
| After Warranty Service: | Video Technical Support, Online Support | Local Service Location: | None |
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert | Showroom Location: | None |
| Port: | Shanghai | ||
| High Light: | 10kg used industrial robot KR 10,KUKA Mig Mag Welding Machine,used industrial robot R1420 |
||
Product Description
Used Industrial robot KR 10 R1420 with 10kg rated payload robotic welding with 6 axis robot arm mig mag welding machine
The KR 10 R1420 is designed for a rated payload of 10 kg in order to optimize the dynamic performance of the robot. With reduced load center distances, higher loads up to the maximum payload may be used. The specific load case must be verified using KUKA.Load.
Main Specifications:
Maximum reach :1420 mm
Maximum payload :10 kg
Pose repeatability (ISO 9283) :± 0.04 mm
Number of axes :6
Footprint: 333.5 mm x 307 mm
Weight approx. :160 kg
Controller :KR C4 compact
Teach pendant :KUKA smartPAD
| Specification | |
| Maximum reach | 1420 mm |
| Maximum payload | 10 kg |
| Pose repeatability (ISO 9283) | ± 0.04 mm |
| Number of axes | 6 |
| Mounting position | Floor/ Ceiling/Wall |
| Footprint | 333.5 mm x 307 mm |
| Weight | approx. 160 kg |
| Protection rating | IP65 |
| Controller | KR C4 compact |
| Teach pendant | KUKA smartPAD |
| Motion range | |
| A1 | ±170° |
| A2 | (-185° / 65°) |
| A3 | (-137°- 163°) |
| A4 | ±185° |
| A5 | ±120° |
| A6 | ±350° |
Applications:
Arc welding , Spotwelding , Press tending , Loading and unloading of parts , Machining , Handling of parts , Measurement , Assembly of parts
