7 Axis Used Yaskawa Robot SIA5F Pick And Place Machine 5kg Payload 559mm
Product Details:
| Place of Origin: | Shanghai, China |
| Brand Name: | Yaskawa |
| Certification: | CE |
| Model Number: | SIA5F |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiable |
| Packaging Details: | 7 axis robot arm YASKAWA SIA5F pick and place machine 5kg Payload 559mm Arm industrial robot<br>ONE YASKAWA SIA5F industrial robot 7 Axis robot arm for pick and place machine packing with fumigation wooden frame, WG:105KG<br>Controller and other parts pack |
| Supply Ability: | 5 Piece/Pieces per Month |
|
Detail Information |
|||
| Product Name: | 7 Axis Robot Arm YASKAWA SIA5F Pick And Place Machine Industrial Robot | Function: | Multifunctional |
|---|---|---|---|
| Controlled Axes: | 7 | Max. Payload: | 5kg |
| Repeatability: | ±0.06mm | Max. Working Range R: | 559mm |
| Temperature: | 0-40 ℃ | Humidity: | 20%-80% |
| Weight: | 30kg | Power Supply, Average: | 1.0KVA |
| Condition: | New | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | Ordinary Product |
| Warranty Of Core Components: | 1 Year | Core Components: | PLC, Engine, Bearing, Gearbox, Motor, Gear |
| Warranty: | 1 Year | After-sales Service Provided: | Free Spare Parts, Field Maintenance And Repair Service, Video Technical Support, Online Support |
| After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service | Local Service Location: | United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, India, Russia, Thailand, Japan, South Korea |
| Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Printing Shops, Construction Works , Energy & Mining, Advertising Company | Showroom Location: | Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Indonesia, India, Mexico, Russia, Spain, South Korea, Bangladesh, Nigeria, Japan, Malaysia, Australia |
| Port: | Shanghai | ||
| High Light: | 7 axis Used Yaskawa Robot,7 axis robot arm 559mm,Used Yaskawa Robot SIA5F |
||
Product Description
7 axis robot arm YASKAWA SIA5F pick and place machine 5kg Payload 559mm Arm industrial robot
Main Specifications:
Model:SIA5F
Maximum reach:559mm
Maximum payload:5kg
Pose repeatability:± 0.06mm
Number of axes:7
Weight:30kg
| Product Name | 7 axis robot arm YASKAWA SIA5F pick and place machine 5kg Payload 559mm Arm industrial robot |
| Model | SIA5F |
| Application | Flexible applications |
| Maximum reach | 559mm |
| Maximum payload | 5kg |
| Pose repeatability (ISO 9283) | ± 0.06mm |
| Number of axes | 7 |
| Mounting position | Floor, ceiling, wall |
| Weight | 30kg |
| Protection rating | IP67 |
| Controller | FS100 |
| Motion range | |
| S | 180° to -180° |
| L | 110° to -110° |
| U | 90° tp -115° |
| R | 180° to -180° |
| B | 110° to -110° |
| T | 180° to -180° |
SIA5F Introduction:
The SIA-series are small and agile 7-axis robots providing "human-like" flexibility of movement and fast acceleration.They distinguish themselves through slim and lightweight design. They offer high payload and big working ranges.
These agile and versatile robots open up a wide range of industrial applications: ideal for assembly, injection moulding, inspection, machine tending and a host of other operations.
This robots are driven by the compact MOTOMAN FS100 controller.
KEY BENEFITS
• 7 axes
• Flexible applications
• Compact design allows maximum performance
Applications:
Flexible applications
